HOW TO DESIGN IRONMAN'S HELMET EASILY IN AUTOCAD 2022 ?

      HOW TO DESIGN IRONMAN'S HELMET BY USING  AUTOCAD 2022?

Everyone likes Ironman and we are eager to make ironman suits. So it's time to design an  Ironman helmet easily in 2-D level by using AutoCAD 2022.

 REQUIRED COMMANDS:

Type the following commands in the command box at the required time.

• UNIT
• LIMIT
• ZOOM
• DST
• XLINE
• LINE
• ARC
• MIRROR
• HATCH
•


               STEPS FOR DESIGNING IRONMAN'S HELMET DIAGRAM:

• First of all, type the UNIT command and select the appropriate unit type and precision level.

• Type LIMIT command and type appropriate lower corner level limit and upper corner level limit. (<0,0>,<297,420> is a suggestible limits)

• Type the ZOOM command and choose 'All'.

•  Type DST(Dimension Style) command and select 'New style'. Create your own dimension style.

•  The above four commands are common to all drawing works.

• Then, insert reference ironman's help picture for your reference by using this step (INSERT in the menu bar> ATTACH> Picture from your computer>OK).

•






•  The above image(for reference) will be shown. Then draw a reference line along the y-axis by using XLINE Command.

•  First, draw a bottom horizontal line by using the LINE command (For designing lower jaw.)

•  At the starting end of a horizontal line, draw another slanting line with the appropriate angle. (For drawing slant line, we should turn off an ortho mode by clicking the F8 button.)

•  Again follow the above step with a lesser angle value.

•  Draw an arc by using the ARC command (Start, End, Direction option is preferable.) for drawing the head portion. The half outline portion is completed.

•  For drawing the inner portion, first, draw the mouth section by using the LINE command.

•  Then draw an arc between two lines by using the ARC command.

•  Draw an eye section by using the LINE command and complete the remaining parts from the reference picture by using LINE and ARC Command.

• It's enough to draw half portion of the helmet.

• Then create a remaining part by using the MIRROR command. Type MIRROR in the command box>select the required objects>Specify the first point of mirror line>Specify the second point of mirror line> Choose source object whether it is disappeared or not.

•   Ironman's face diagram is required.

• Then fill in the required color by using the HATCH command. Type HATCH option from the draw tool bar>Choose hatch type (Solid type is preferable.) > Fill a required color by picking points option in the required portions.

✌ Finally, you designed the Ironman's helmet 2-D diagram in the AutoCAD 2022.✌

👍👍👍

❗NOTE:❗

💬If you have any doubts regarding the above diagram, kindly put it in the comment section.💬
